主要技术参数 Main technical parameters
型号Type | 额定电压(V) Rated voltage |
额定电流(A) Rated current |
进线口螺纹 Inlet thread (G") |
电缆外径 Cable outer dia.(mm) |
|
BLN-□ | AC220V AC380V DC24V DC48V DC110V DC220V |
6 2 6 2.5 1.6 0.25 |
G1/2" G3/4" |
φ6~φ10 φ9~φ14 |
防爆标志 Ex-mark |
防腐等级 Erosion-proof-class |
防护等级 Degree of protection |
ExedⅡBT6等效于 Ⅱ2G ExedⅡBT6(欧标) ExedmⅡCT6等效于 Ⅱ2G ExedmⅡCT6(欧标) DIP A20 TA,T6等效于 Ⅱ1D ExtD A20 T6(欧标) |
WF1,WF2* | IP65,IP66* |
*.要求IP66,需注明。IP66 Requirements must be marked
